How To Create a Clock In Angular

Introduction



In this article, I will explain about how to create a clock using Angular.



Prerequisites

• Angular 7
• HTML/Bootstrap

In this article we will learn how to create a clock using canvas in Angular.



For this article, I have created an Angular project using Angular 7. For creating an Angular project, we need to follow the following steps:



Step 1



I have created a project using the following command in the Command Prompt.

ng new clockexample

Step 2



Open a project in Visual Studio Code using the following commands.

cd clockexample
code.

Step 3



Create a new component using the following commands.

ng g c clock

Import the following image in Assets folder:







Import the following dependancy in clock.component.ts:

import { Component, ViewChild, ElementRef, Input, OnInit, AfterViewInit, OnDestroy } from '@angular/core';
import { ChangeDetectionStrategy, NgZone } from '@angular/core';
import { Observable, timer, Subscription } from 'rxjs';
import { timeInterval, tap, map } from 'rxjs/operators';
import { TDate } from '../tdate';
import { formatDate } from '@angular/common';
import { DatePipe } from '@angular/common';

clock.component.ts



Add the following code in clock.component.ts:

import { Component, ViewChild, ElementRef, Input, OnInit, AfterViewInit, OnDestroy } from '@angular/core';
import { ChangeDetectionStrategy, NgZone } from '@angular/core';
import { Observable, timer, Subscription } from 'rxjs';
import { timeInterval, tap, map } from 'rxjs/operators';
import { TDate } from '../tdate';
import { formatDate } from '@angular/common';
import { DatePipe } from '@angular/common';
@Component({
  selector: 'cs-canvas-clock',
  template: '<canvas #mycanvas></canvas>',
  styles: [],
  changeDetection: ChangeDetectionStrategy.OnPush
})
export class ClockComponent implements OnInit, OnDestroy, AfterViewInit {
  @ViewChild('mycanvas', { static: false, read: ElementRef }) canvasRef: ElementRef;
  public tdate=new Date();
  @Input() public width = 100;
  @Input() public height = 100;
  canvasContext: CanvasRenderingContext2D;
  subscription: Subscription;
  constructor(private ngZone: NgZone,private datePipe: DatePipe) {
  }

  ngOnInit() { }
  ngAfterViewInit() {
    const canvasEl: HTMLCanvasElement = this.canvasRef.nativeElement;
    canvasEl.width = this.width;
    canvasEl.height = this.height;
    const radius = canvasEl.height / 2;
    const innerRadius = radius * 0.89;
    this.canvasContext = canvasEl.getContext('2d');
    this.canvasContext.translate(radius, radius);
    this.ngZone.runOutsideAngular(() => this.draw(innerRadius));
  }
  ngOnChanges(change) {
    if (this.subscription) {
      this.subscription.unsubscribe();
    }
    if (change.tdate) {
      this.tdate = change.tdate.currentValue;
      if(this.canvasRef)
      {
        const canvasEl: HTMLCanvasElement = this.canvasRef.nativeElement;
        canvasEl.width = this.width;
        canvasEl.height = this.height;
        const radius = canvasEl.height / 2;
        const innerRadius = radius * 0.89;
        this.canvasContext = canvasEl.getContext('2d');
        this.canvasContext.translate(radius, radius);
        this.ngZone.runOutsideAngular(() => this.draw(innerRadius));
      }
    }
  }
  ngOnDestroy() {
  }
  draw(innerRadius: number) {
    this.drawBackground(this.canvasContext, innerRadius);
  }

  drawBackground(canvasContext, innerRadius) {
    var background = new Image();
    let date =new Date(this.tdate) ;
    let dp= this.datePipe;
    let am_pm=dp.transform(date,"a");
    if(am_pm=='AM' && background.src != "/assets/clockAM.png")
    {
      background.src = "/assets/clockAM.png";
    }
    else if(am_pm=='PM' && background.src != "/assets/clockPM.png")
    {
      background.src = "/assets/clockPM.png";
    }
    let $this = this;
    background.onload = function () {
      $this.subscription = timer(0, 1000)
        .pipe(
          tap(t => {
            canvasContext.clearRect($this.width / 2 * -1, $this.height / 2 * -1, $this.height, $this.width);
            date=new Date(date.setSeconds(date.getSeconds()+1));
            canvasContext.drawImage(background, -50, -50, 100, 100);
            $this.drawTime(canvasContext, innerRadius,date);
          })
        )
        .subscribe(s=>{
        }
        );
    }
  }
  drawFace(ctx, radius) {
    ctx.beginPath();
    ctx.arc(0, 0, radius, 0, 2 * Math.PI);
    ctx.fillStyle = 'white';
    ctx.fill();
    const grad = ctx.createRadialGradient(0, 0, radius, 0.95, 0, 0, radius, 1.05);
    grad.addColorStop(0.5, '#333');
    grad.addColorStop(0, '#1ABB9C');
    ctx.strokeStyle = grad;
    ctx.lineWidth = radius * 0.050;
    ctx.stroke();
    ctx.beginPath();
    ctx.arc(0, 0, radius, 0.1, 0, 2, Math.PI);
    ctx.fillStyle = '#333';
    ctx.fill();
  }

  drawNumbers(ctx, radius) {
    let ang;
    let num;
    let dot = '.';
    ctx.font = radius * 0.1 + 'px arial';
    ctx.font = "10pt Courier";
    ctx.textBaseline = 'middle';
    ctx.textAlign = 'center';
    for (num = 1; num < 13; num++) {
      ang = num * Math.PI / 6;
      ctx.rotate(ang);
      ctx.translate(0, -radius * 0.85);
      ctx.rotate(-ang);
      ctx.fillText(dot, 0, 0);
      ctx.rotate(ang);
      ctx.translate(0, radius * 0.85);
      ctx.rotate(-ang);
    }
  }

  drawTime(ctx, radius,date) {
    const { seconds, minutes, hours } = new TDate(date);
    const hourHand =
      (hours % 12) * Math.PI / 6 + minutes * Math.PI / (6 * 60) + seconds * Math.PI / (360 * 60);
    //this.drawHand(ctx, hourHand, radius * 0.5, radius * 0.07);
    this.drawHourHand(ctx, date, radius * 0.6, radius * 0.05);
    const minuteHand = minutes * Math.PI / 30 + seconds * Math.PI / (30 * 60);
    this.drawMinuteHand(ctx, date, radius * 0.8, radius * 0.04);
    //this.drawHand(ctx, minuteHand, radius * 0.8, radius * 0.07);
    const secondHand = seconds * Math.PI / 30;
    this.drawSecondHand(ctx, date, radius * 0.9, radius * 0.03);
    //this.drawHand(ctx, secondHand, radius * 0.9, radius * 0.02);
  }

  // drawHand(ctx, pos, length, width) {
  //   ctx.beginPath();
  //   ctx.lineWidth = width;
  //   ctx.lineCap = 'round';
  //   ctx.moveTo(0, 0);
  //   ctx.rotate(pos);
  //   ctx.lineTo(0, -length);
  //   ctx.stroke();
  //   ctx.rotate(-pos);
  // }

  degreesToRadians(degrees) {
    return (Math.PI / 180) * degrees
  }

  drawHourHand(ctx, theDate, length, width) {
    var hours = theDate.getHours() + theDate.getMinutes() / 60;

    var degrees = (hours * 360 / 12) % 360;

    ctx.save();
    ctx.fillStyle = 'black';
    ctx.strokeStyle = '#555';

    ctx.rotate(this.degreesToRadians(degrees));

    this.drawHand(ctx, length, width, 3);

    ctx.restore();

  }

  drawMinuteHand(ctx, theDate, length, width) {
    var minutes = theDate.getMinutes() + theDate.getSeconds() / 60;

    ctx.save();
    ctx.fillStyle = 'black';
    ctx.strokeStyle = '#555';
    ctx.rotate(this.degreesToRadians(minutes * 6));

    this.drawHand(ctx, length, width, 5);

    ctx.restore();
  }

  drawHand(ctx, size, thickness, shadowOffset) {
    thickness = thickness || 4;

    // ctx.shadowColor = '#555';
    // ctx.shadowBlur = 10;
    // ctx.shadowOffsetX = shadowOffset;
    // ctx.shadowOffsetY = shadowOffset;

    ctx.beginPath();
    ctx.moveTo(0, 0); // center
    ctx.lineTo(thickness * -1, -10);
    ctx.lineTo(0, size * -1);
    ctx.lineTo(thickness, -10);
    ctx.lineTo(0, 0);
    ctx.fill();
    ctx.stroke();
  }

  drawSecondHand(ctx, theDate, length, width) {
    var seconds = theDate.getSeconds();
    ctx.save();
    ctx.fillStyle = '#1ABB9C';
    ctx.strokeStyle = "#1ABB9C";
    ctx.globalAlpha = 0.8;
    ctx.rotate(this.degreesToRadians(seconds * 6));

    this.drawHand(ctx, length, width, 0);

    ctx.restore();
  }

}

App.module.ts

import { BrowserModule } from '@angular/platform-browser';
import { NgModule } from '@angular/core';
import {  DatePipe } from '@angular/common';
import { AppRoutingModule } from './app-routing.module';
import { AppComponent } from './app.component';
import { ClockComponent } from './clock/clock.component';

@NgModule({
  declarations: [
    AppComponent,
    ClockComponent
  ],
  imports: [
    BrowserModule,
    AppRoutingModule,

  ],
  providers: [DatePipe],
  bootstrap: [AppComponent]
})
export class AppModule { }

App.components.html

<span height="70" align="right" class="float-right" id="canvasClock">
  <cs-canvas-clock></cs-canvas-clock>
</span>

Now, run the project using the following command:

ng serve

Summary



In this article, I have discussed how to create a clock using canvas in Angular.
